Specifications

Specifications:

Reaction Incubation Method: Dry bath system

Reaction Temperature: Dry bath: 37± 0.3 °C (98.6± 0.5 °F)

Reaction Solution Amount: • 80 to 287 µL

System Specifications

Reaction System Specifications

Reaction Time: Maximum 8 minutes 40 seconds

Mixing System: Rotative mixing bar system

Reaction Cell:Glass square cuvette (optical path length: 5 mm)

Reaction Line: Rotary disk system: 204 cuvettes x 2 lines

Analytical Method Specifications

Photometric points: 28

Type of Measurement:

• End point assay
• Rate assay
• Fixed point assay
• Electrode method (ISE) (option)

Optical System Specifications

Photometer: Multi-wavelength diffraction grating spectrophotometer Photometric Modes: Monochromatic or bichromatic Wavelengths 340 to 800 nm (13 steps of 340, 380, 410, 450, 480, 520, 540, 570, 600, 660, 700, 750, and 800 nm)

Photodetector: Silicon photodiode array

Light Source: Halogen lamp 12 V/100 W

Measurable Absorbance Range: 0 to 3.0 Abs (converted in units of 10 mm of optical path length)

Photometric resolution: 0.0001 Abs
